STAMFORD P7

kVA Range
2325-2800
Frequency
50/60Hz

The STAMFORD® P7 4 pole is now a discontinued product and has been replaced with STAMFORD® S7. The P7 is still available as a 6 pole product.

The STAMFORD® P7 has a maximum continuous rating of 2800kVA at 60Hz (2,325kVA at 50Hz) and a voltage output of 380-690 volts.

The STAMFORD® P7 benefits from high efficiency and good electrical performances, enabling good specification matching for grid code applications and combined heat and power. The P7 proven design in the marine market makes it a preferred product for meeting the demanding marine societies’ performance standards.

Specifications

Product Specifications

50Hz Continuous (kVA)
2325.00
60Hz Continuous (kVA)
2800.00
Voltage Designation
Low
Voltage Range
380-690
AVR
MX341 with PMG
Poles
4/6
Winding Pitch
2/3
Options

Product Options

Ingress Protection
IP23
AVR Options
DECS150
DM110
MX321 with PMG
No AVR
DECS 100 with PMG
Material Insulation Class
H
Excitation System
PMG
Options
3 phase sensing
Double Bearing Arrangement
IP23 Air Filters
IP44 Air Filters
Thermistors
Winding RTDs
Anti-Condensation Heaters
